RW 420 Print Station

Standard Features

• Charges and holds either the MC55/MC65 terminal (MC5590, MC55A0, MC65) or the MC70/MC75 terminal (MC7004, MC7090, MC7094, MC7095, MC7098, MC75) all with up to a 2x battery
• DEX communications interface
• Serial RS-232

More Standard Features

• USB 2.0 full speed
• Print method: Direct thermal
• Smart battery management (monitors battery for longer life and performance)
• 5 button keypad LCD (standard)
• Resident scalable fonts
• Advanced 32 bit architecture for high-speed processing
• Standard Serial and USB interfaces
• Programming Language: Native CPCL, ZPL, EPL and XML support(standard)
• Supports vertical or horizontal printing
• Auto-detect firmware load

  Note: Please see product datasheet/brochure for additional operating characteristic details.

Printer Specifications

Resolution 203 dpi (8 dots/mm)
Memory

• 8 MB Flash
• 16 MB DRAM

Print width 4.10" (104.1 mm) maximum
Print length Maximum print length at least 36" (914 mm) - actual length depends upon total memory usage
Print speed 3" (76mm)/sec

Optional Features

• BT
• Card readers

Media Characteristics

Maximum media width = 4.25" (108 mm)
Minimum media width = 2.0" (50.8 mm)
Maximum roll diameter 2.25" (57 mm)
Core diameter .75" (19 mm) or 1.38" (34.9 mm)
Media thickness .002" (.05 mm) to .0063" (0.16 mm)
Media types continuous receipt, gap, receipt, tag

Operating Characteristics

Operating temperature DT: Operating temperature -4° F (-20° C) to 131° F (55° C) Direct thermal
Storage temperatures -22° F (-30° C) to 149° F (65° C)
Operating humidity 10–80% non-condensing
Storage humidity 10–90% non-condensing
Electrical

• Standard Battery: 7.4 V, 4.0 Ahr removable, rechargeable Li-Ion battery (1400 six-inch receipts (8400") at 30% black density at room ambient temperature, tone 0)
• Input Voltage: 12 VDC, nominal
• Maximum Recharging current: 5A max
• Agency approvals: FCC Part 15 Class B, ICES-003, VCCI, NOM/NYCE, CE compliance (Class B), C-Tick

Physical Characteristics

Height 7.62" (193.5 mm)
Depth 2.83" (71.9 mm)
Weight 3.25 lbs (1.47 kg)

Related Products

Options

• Magnetic stripe reader and EMV™ level one certified smart card reader
• Lithium ion fast AC charger
• Lithium ion quad charger
• Lithium ion DC charger with cigarette lighter adapter
• Fanfold bin
• Vehicle cradle for docking and charging
• Ram mount kit
• Shoulder strap/ hand strap
• Environmental soft case
• Fanfold media support
• Wireless Security Support (ie. 802.11i, VPN, WPA or WPA2)

Communication and Interface Capabilities

• Bluetooth (Optional)
• Standard cable connection: RS-232, RJ-45 10 pin
• Standard USB 2.0 full speed

PROGRAMMING LANGUAGES

Core programming languages ASCII EPL2, CPCL-native, ZPL II, XML, EPL, EPL2

Bar Code/ Symbologies

Linear Codabar
Code 128
Code 39
Code 93
EAN-13
EAN-14
EAN-8
FIM
Interleaved 2-of-5
MSI
Plessey
Postnet
UCC/EAN-128
2-dimensional Data Matrix
MaxiCode
PDF417
QR Code
RSS / GS1 DataBar family (12 barcodes)
Fonts and Graphics

• Standard Fonts: 25 bitmapped, 1 smooth, scalable (CG Triumvirate Bold Condensed);
• Optional Fonts: downloadable bitmapped and scalable fonts
• International Character Sets (optional):
  Chinese 16x16 (trad), 16x16 (simplified), 24x24 (simplified)
  Japanese 16x16, 24x24
  Hebrew/Arabic
• Standard resident fonts can be rotated in 90° increments
• Supports user-defined fonts and graphics--including custom logos
• Text concatenation to assign different character styles
• Allows text magnification 1-16 times the original size
• Proportional and fixed-width fonts
